AstroMax C24
TRADE PRICE
$5,390inc GST
RRP
$10,700inc GST
Buy In Bulk & Save
Buy 3 Units - $5,390
Buy 6 Units - $5,390
Buy 12 Units - $5,390
24kW single-phase pool heat pump for pools up to 80,000L. Inverter compressor, titanium heat exchanger, R32 refrigerant and Wi-Fi control. 5-year parts and 10-year compressor warranty. Trade pricing applies at checkout for approved accounts.
Add in your recommended retail markup.
5 Years Heat Pump Unit & Components
15 Years Compressor
25 Years Heat Exchanger
KEY FEATURES
Why the AstroMax C24?
Warm water, faster
Turbo mode lifts output when you need it, so your pool is ready sooner after cold spells or a fresh fill.
Kind on running costs
High-efficiency R32 technology draws warmth from the air, keeping the water warm for a fraction of what gas costs.
Backed for the long term
5-year parts and 10-year compressor warranty, plus a 48-hour on-site service promise in writing.
Efficient. Single-Phase. Versatile.
The AstroMax C24 delivers 24kW of single-phase pool heating, a strong all-rounder for medium pools up to 80,000L. Backed by a 5-year parts and 10-year compressor warranty, with CHR's 48-hour on-site service guarantee.
Key Features
Turbo Mode
Turbo Mode increases heat output by 20% during peak demand periods, reducing heat-up time on initial pool fills and after extended cold periods.
R32 Refrigerant
R32 refrigerant - lower GWP than R410A, rated COP up to 15. Higher efficiency at Australian ambient temperatures, lower running costs.
5yr Parts / 10yr Compressor
5yr parts warranty. 10yr compressor warranty. Backed by 48-hour on-site service - in writing.
Full Specifications
| Model | AstroMax C24 — 24kW |
| Heating Capacity at Air 26°C, Humidity 80%, Water 26°C in, 28°C out | |
| Heating Capacity (kW) | 21.42~4.86 |
| Power Input (kW) | 3.07~0.30 |
| COP | 15.96~6.98 |
| Heating Capacity at Air 15°C, Humidity 70%, Water 26°C in, 28°C out | |
| Heating Capacity (kW) | 15.92~3.61 |
| Power Input (kW) | 3.19~0.47 |
| COP | 7.68~4.99 |
| Cooling Capacity at Air 35°C, Water 28°C in, 27°C out | |
| Cooling Capacity (kW) | 11.60~2.96 |
| Power Input (kW) | 3.06~0.43 |
| EER | 6.93~3.79 |
| Power Supply | 220~240V / 1 / 50Hz |
| Rated Power Input (kW p/h) | 3.2 |
| Compressor | Inverter |
| Fan Motor | DC Motor |
| Controller | Inverter |
| Wifi Control | Yes |
| Heat Exchanger | Titanium |
| Noise Level (dBa) at 1m | <41~<49 |
| Noise Level (dBa) at 10m | <23~<31 |
| Unit Net Dimensions (L/M/H) | 965*400*745mm |
| Unit Net Weight | 58Kg |
Compare the C24 against the full AstroMax range to match output to pool size.
| Model | Output | Pool Size | Trade Price | RRP | Your Markup |
| AstroMax W17 | 17kW | Up to 50,000L | $4,290 inc GST | $7,700 inc GST | $3,410 inc GST |
| AstroMax C24This model | 24kW | Up to 80,000L | $5,390 inc GST | $10,700 inc GST | $5,310 inc GST |
| AstroMax H35 Turbo | 35kW | Up to 130,000L | $7,590 inc GST | $14,700 inc GST | $7,110 inc GST |
| AstroMax 35T | 35kW | Up to 130,000L | $7,590 inc GST | $14,700 inc GST | $7,110 inc GST |
| AstroMax R40 | 40kW | Up to 160,000L | $8,690 inc GST | $16,900 inc GST | $8,210 inc GST |
